Description
-
Detail
Meassuring range 0 to 10 m/s Nominal Sizes From DN 15 to DN 1000 (½” to 40″) Accuracy ± 0.5 % of flow rate Operating pressure Max. 40 bar (Max. 580 psi) Ambient temperature From -20 to 60 °C (-4 to 140 °F) Medium temperature From -20 to 150 °C (-4 to 300 °F) Liners Neoprene
PTFE
Hardrubber
Linatex
NovolakElectrodes AISI 316 Ti (mat. No. 1.4571/316 Ti)
Hastelloy C4 (mat. No. 2.4610)
Platinum head with shaft (mat. No. 1.4571/316Ti)
Titanium
TantalumEnclosure sensor IP67 (NEMA 4x)
IP68 (NEMA 6) – optionalMaterial Carbon steel - Built-in advanced batch control
- Robust aluminum two-chamber die-cast housing suitable for potentially explosive applications
- Built-in dosing function
- Added communication module for easy integration with your application, providing a fully integrated solution throughout the plant
- EMC requirements as well as high functional safety and system availability due to uniform operating concept according to NAMUR guidelines are fulfilled
- Error behavior according to NE43 for 4 … 20mA output selectable
- Improved troubleshooting and testing of the instrument through comprehensive diagnostics and service menu
- SENSORPROM technology allows transmitter replacement and automatic reprogramming of a new transmitter without loss of data or accuracy
- Keypad and alphanumeric display are intrinsically safe and programmable directly in the hazardous area – ATEX and FM certified
