Description
| Brand |
Micro Motion |
|---|
As a B2B supplier, we offer the Micro Motion F200H Coriolis Meter, ensuring timely delivery with our strong supply chain and quick response capabilities to help optimize your production processes. Our professional after-sales service team is always available to provide technical support, ensuring your equipment remains in peak condition. Choose the F200H to enhance your measurement efficiency and business competitiveness.
| Specification | Value |
|---|---|
| Mass flow accuracy (Liquid) | ±0.20% of rate (standard), ±0.15% of rate (optional), ±0.10% of rate (optional) |
| Mass flow repeatability (Liquid) | ±0.050% of rate |
| Volume flow accuracy (Liquid) | ±0.20% of rate (standard), ±0.15% of rate (optional), ±0.10% of rate (optional) |
| Volume flow repeatability (Liquid) | ±0.050% of rate |
| Mass flow accuracy (Gas) | ±0.5% of rate |
| Mass flow repeatability (Gas) | ±0.25% of rate |
| Density accuracy (Liquid) | ±0.002 g/cm³ (2.0 kg/m³) (standard), ±0.001 g/cm³ (1.0 kg/m³) (optional), ±0.0005 g/cm³ (0.5 kg/m³) (optional) |
| Temperature accuracy | ±1 °C ±0.5% of reading |
| Sensor maximum working pressure | 2,160 psig (149 barg) |
| Meter approvals, calibrations, and certifications | UL, CSA, IECEx, NEPSI, ATEX, Ingress Protection, EMC effects |
Micro Motion F200H Coriolis Meter
| Feature | Description |
|---|---|
| Measurement Accuracy | Achieve highly accurate mass volume flow and density measurement in applications that require a compact, drainable design |
| Material Options | Choose from 316L Stainless Steel and C-22 nickel alloy in all sizes |
| Diagnostics | Improve measurement and tracking with extensive process and meter diagnostics with on-board historian and logging |
| Certifications | Broad range of meter approvals and certifications, including; CSA, ATEX, IECEx, Ingress Protection 66/67, and NAMUR |
| Custody Transfer Approvals | Custody Transfer Approvals from MID OIML R 117, NTEP, Measurement Canada, and INMETRO Brazil |
| Response Rates | Realize the fastest response rates and accurate batch and process measurement with unmatched MVD transmitter technology |
| Integrity Assurance | Gain real-time and in-process measurement integrity assurance with Smart Meter Verification |
| 3D Model Interaction | Interact with our 3D model to learn more about our F-Series Coriolis Flow and Density Meters |
