Rosemount

Rosemount 0085 Temperature Sensor and Rosemount 644 Temperat

As a trusted supplier, we offer the Rosemount 0085 Pipe Clamp Temperature Sensor and Rosemount 644 Temperature Transmitter, designed for industrial use with high durability and precision. Both products are certified for hazardous environments and ensure reliable performance. With fast shipping, customizable calibration options, and expert technical support, we provide everything you need to meet your temperature measurement requirements.

Brand

Rosemount

Purchase details

Free Online Product Selection Service

Fast Quoting & Competitive pricing

Min. order: 1 piece & 2-Year Warranty

Specification

Rosemount 0085 Pipe Clamp Temperature Sensor Rosemount 644 Temperature Transmitter

Pipe Clamp Materials: ASTM 304 SST (1.4301), Duplex F51 (1.4462), Carbon steel (1.0037)
Input: Dual and single sensor capability with universal sensor inputs (RTD, T/C, mV, ohms)

Lead Wires: PTFE insulated, silver-coated copper wire
Output Signal: 4-20 mA /HART™ protocol, FOUNDATION™ fieldbus protocol, PROFIBUS™ PA protocol

Insulation Resistance: 1,000 MΩ minimum insulation resistance when measured at 500 V dc at room temperature
Housing: Field mount, DIN A head mount or rail mount

Calibration Options: Class A Sensor from -50 to 300 °C (-58 to 572 °F)
Display/Interface: LCD Display, LCD Display with Local Operator Interface (LOI), or LED

Certifications/Approvals: Hazardous location, see full specs for complete list of certifications
Diagnostics: Basic diagnostics, Hot Backup™ capability, sensor drift alert, thermocouple degradation, min/max tracking

Calibration Options: Transmitter-sensor matching (Callendar-Van Dusen constants), 5-point calibration

Certifications/Approvals: SIL 2/3 certified to IEC 61508 by an independent 3rd party, hazardous location, marine type, see full specs for complete list of certifications
